REM-100
6 inch Recessed Emergency New construction Halogen JC Type
DESCRIPTION
■ For Direct contact with thermal insulation
■ Thermally protected
■ Wire through junction box
■ Four Romex pryouts with strain relief
■ Intergral T-Bar installation slots
■ Adjustable Hanger bar with 16" to 25" joist span
■ Trim Option : Plastic Gimbal Ring (included)
■ Battery : 120V / 277VAC, 60Hz, 6V, 4.0AH / 2HR
■ Electrical feature :
Input : 120V / 277VAC, 60Hz,10W, 0.05A
Output : 6VDC, 90Min, 8W
Lamp : Halogen JC type, 8W / 6V (included)
■ Listings : UL Listed
■ Thermally protected
■ Wire through junction box
■ Four Romex pryouts with strain relief
■ Intergral T-Bar installation slots
■ Adjustable Hanger bar with 16" to 25" joist span
■ Trim Option : Plastic Gimbal Ring (included)
■ Battery : 120V / 277VAC, 60Hz, 6V, 4.0AH / 2HR
■ Electrical feature :
Input : 120V / 277VAC, 60Hz,10W, 0.05A
Output : 6VDC, 90Min, 8W
Lamp : Halogen JC type, 8W / 6V (included)
■ Listings : UL Listed
USE TRIM
White Gimbal
Emergency Trim
Black Gimbal
Emergency Trim
