H590ICA

5 inch IC Slope Incandescent New construction Housing (Max. 75W)
DESCRIPTION
Housing
■ Designed for use in ceiling with slopes from 2/12 to 6/12.


Junction Box
■ Listed for through branch circuit wiring.
■ Contains seven 7/8" knockouts and four Romex pryouts with strain relief.


Socket
■ The socket aiming mechanism allows the lamp to be aimed straight down regardless of ceiling pitch.


Bar Hanger
■ Pre-installed Real nail easily install in regular lumber, engineered lumber.
■ Bar Hangers are adjustable from 13 - 5/8" to 25" and can be repositioned 90 degree on plaster frame.


Thermal Protector
■ Self resetting thermal protector deactivates fixture if overheating occurs due to improper lamping or misapplied insulation.


Listings
■ cULus Listed for Damp Location
■ cULus Listed for Feed Through
■ Certified under ASTM-E283 for Air tight construction
5 INCH SLOPE TRIMS
